DIFFERENTIAL (REAR) 7F-7
b) Remove differential left case (2) from differential right case
(1).
c) Remove pinion shafts, differential gears, washers, differen-
tial pinions, spring washers, thrust washers.
4) Using special tools, pull out differential side bearings (1).
Special tool
(C) : 09913-85230
(D) : 09913-61510
5) Remove drive bevel pinion (hypoid gear) assembly.
a) Hold universal joint flange with special tool and then
remove flange nut by using power wrench (4 - 10 magnifica-
tion) (2).
Special tool
(E) : 09922-66021
2
1
1. Socket wrench
To Next Page
