9-18 BODY SERVICE
“a” : 30 mm (1.18 in.) 1. Main floor 6. Extension floor
“b” : 100 mm (3.94 in.) 2. Front fender 7. Center floor
“A” : Apply undercoating (PVC, 400 µm or more) 3. Front wheel housing 8. Rear floor
“B” : Add undercoating (PCV) to cover edges and mating parts 4. Frame 9. Side sill inner
5. Dash panel 10. Side sill outer
A
A
B
B
Z
3
2
“A”
4
“B”
“A”
“A”
“B”
“B”
“B”
“B”“B”
“b”
“a”
“B”
8
910
7
6
5
1
“A”
1
“A”“A”“A”
“A”
“A”
C
C
A – A
C – C
B – B
VIEW: Z
