AIR BAG SYSTEM 10B-41
DTC WILL SET WHEN
DTC B1041 and B1045 :
The resistance of driver or passenger seat belt pretensioner initiator circuit is above a specified value for speci-
fied time.
DTC B1042 and B1046 :
The resistance of driver or passenger seat belt pretensioner initiator circuit is below a specified value for speci-
fied time.
DTC B1043 and B1047 :
The voltage measured at driver or passenger seat belt pretensioner initiator circuit is below a specified value for
specified time.
DTC B1044 and B1048 :
The voltage measured at driver or passenger seat belt pretensioner initiator circuit is above a specified value for
specified time.
TABLE TEST DESCRIPTION
DTC B1041, B1042, B1043, B1044, B1045, B1046, B1047 and B1048 :
STEP 1 : Check whether malfunction is in seat belt pretensioner.
STEP 2 : Check seat belt pretensioner initiator circuit in air bag harness.
DIAGNOSTIC FLOW TABLE
DTC B1041 and B1045 :
Step Action Yes No
1 1) With ignition switch OFF, remove center
pillar inner garnish of applicable side then
disconnect seat belt pretensioner connec-
tor.
2) Check proper connection to applicable
seat belt pretensioner at terminals in
“Q11” or “Q12” connector.
3) If OK then connect Special Tool (B) to
seat belt pretensioner connector discon-
nected at the step 1.
With ignition switch ON, is DTC B1041 or
B1045 still current?
Go to step 2. Ignition switch OFF.
Replace seat belt preten-
sioner (Refer to Section
10A).
2 1) With ignition switch OFF, disconnect SDM
connector.
2) Check proper connection to SDM at termi-
nals “Q01-11” and “Q01-12” or “Q01-6”
and “Q01-5”.
3) If OK then measure resistance between
“Q01-11” and “Q01-12” terminals or “Q01-
6” and “Q01-5” terminals with connected
Special Tool (B).
Is resistance 4.5 Ω or less?
Substitute a known-
good SDM and recheck.
DTC B1041 :
Repair high resistance or
open in “PNK” or “WHT” wire
circuit.
DTC B1045 :
Repair high resistance or
open in “BRN” or “LT GRN”
wire circuit.
To Next Page
