Power Assisted Steering System: 6C-54
Specifications
Tightening Torque Specifications
B931G36307001
NOTE
The specified tightening torque is described in the following.
“EPS Control Unit Construction (LT-A750XP/ZK9) (Page 6C-48)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List (LT-A750XP/ZK9) in
Section 0C (Page 0C-7)”.
Special Tools and Equipment
Recommended Service Material
B931G36308001
Fastening part
Tightening torque
Note
N⋅m kgf-m lbf-ft
EPS control unit mounting nut 12 1.2 8.5 )(Page 6C-49)
EPS body assembly mounting bolt 26 2.6 19.0 )(Page 6C-52)
EPS body assembly mounting nut 28 2.8 20.0 )(Page 6C-52)
Steering shaft bolt 26 2.6 19.0 )(Page 6C-52)
Steering shaft upper nut 120 12.0 87.0 )(Page 6C-52)
Handlebar holder nut 60 6.0 43.5 )(Page 6C-53)
Material SUZUKI recommended product or Specification Note
Grease Water resistance grease or
equivalent
P/No.: 99000–25160 )(Page 6C-51) /
)(Page 6C-52)
Thread lock cement THREAD LOCK CEMENT SUPER
“1303” or equivalent
P/No.: 99000–32030 )(Page 6C-52)
