9E-1 Body Structure:
Body and Acc essories
Body Structure
Repair Instructions
Body Frame Construction (LT-A750XP/ZK9)
B931G39506011
Special Tools and Equipment
Recommended Service Material
B931G39508001
NOTE
Required service material is also described in the following.
“Body Frame Construction (LT-A750XP/ZK9) (Page 9E-1)”
FWD
FWD
3
2
4
4
1
I931G3950001-04
1. Frame 3. Washer : Apply thread lock to the thread part.
2. Battery plate 4. Spacer
