Suzuki LT-A750XP/Z User Manual

Service Data: 0C-7
Tightening Torque List (LT-A750XP/ZK9)
B931G30307004
Engine
Item N⋅mkgf-mlbf-ft
Spark plug 11 1.1 8.0
Cylinder head cover bolt
Initial 10 1.0 7.0
Final 14 1.4 10.5
Cam drive idle gear/sprocket shaft 41 4.1 29.5
Intake pipe bolt 9 0.9 6.5
Cylinder head bolt (M6) 10 1.0 7.0
Cylinder head bolt (L200)
Initial 25 2.5 18.0
Final 37 3.7 27.0
Cylinder head bolt (L: 70) 10 1.0 7.0
Cylinder head bolt (L: 100) 10 1.0 7.0
Camshaft journal holder bolt 10 1.0 7.0
Cam chain tension adjuster bolt 10 1.0 7.0
Cam chain tension adjuster cap bolt 7 0.7 5.0
Crankcase bolt (M6) 10 1.0 7.0
Crankcase bolt (M8) 26 2.6 19.0
Valve timing inspection plug 23 2.3 16.5
Clutch shoe nut 150 15.0 108.5
Movable drive face bolt 110 11.0 79.5
Movable driven face bolt 110 11.0 79.5
Movable driven face ring nut 110 11.0 79.5
V-belt outer cover bolt 8 0.8 6.0
V-belt inner cover bolt 9 0.9 6.5
Generator rotor nut 160 16.0 115.5
Generator stator set bolt 11 1.1 8.0
Speed sensor bolt 10 1.0 7.0
Starter clutch bolt 26 2.6 19.0
Exhaust pipe nut 23 2.3 16.5
Muffler connecting bolt 23 2.3 16.5
Muffler mounting bolt 23 2.3 16.5
Engine oil drain plug 21 2.1 15.0
Engine coolant drain plug 13 1.3 9.5
Drive bevel gear nut 100 10.0 72.5
Front output shaft nut 100 10.0 72.5
Engine mounting nut 60 6.0 43.5
Engine mounting damper stopper bolt 23 2.3 16.5
Rear output shaft nut 100 10.0 72.5
Crank balancer drive gear nut 150 15.0 108.5
Crank balancer driven gear bolt 50 5.0 36.0
Starter motor mounting bolt 10 1.0 7.0
Starter motor lead wire connecting nut 6 0.6 4.5
Starter motor housing bolt 5 0.5 3.5
Main oil gallery plug 18 1.8 13.0
Air cleaner box mounting bolt 4.5 0.45 3.0
Left crankshaft spacer nut 38 3.8 27.5
Oil gallery plug (Cylinder head) 10 1.0 7.0
