Power Assisted Steering System: 6C-8
EPS System Wiring Harness Routing Diagram (LT-A750XP/ZK9)
B931G36302003
Refer to “Wiring Harness Routing Diagram (LT-A750XP/ZK9) in Section 9A (Page 9A-4)”.
Component Location
EPS Components Location (LT-A750XP/ZK9)
B931G36303001
1
2
3
4
I931G3630002-02
1. EPS control unit 3. Fuse (EPS)
2. EPS body assembly 4. Mode select coupler
