Drive Chain / Drive Train / Drive Shaft: 3A-1
Driveline / Axle
Drive Chain / Drive Train / Drive Shaft
Repair Instructions
Front Drive Shaft Components (LT-A750XP/ZK9)
B931G33106009
FWD
FWD
1
2
3
7
6
5
4
8
9
10
I931H1310012-03
1. Circlip 6. Inner boot band (Small) : Apply grease.
2. Snap ring 7. Drive shaft : Apply water resistance grease.
3. Stopper ring 8. Outer boot band (Small) : Do not reuse.
4. Inner boot band (Large) 9. Outer boot
5. Inner boot 10. Outer boot band (Large)
