Tektronix AFG3000 Series Reference Manual

Syntax and Commands
AFG3000 Series Arbitrary/Function Generators Reference Manual 3-59
[SOURce[1|2]]:FUNCtion[:SHAPe]
This command sets or queries the shape of the output waveform. When the speci-
fied user memory is deleted, this command causes an error if you select the user
memory.
Group
Source
Syntax
[SOURce[1|2]]:FUNCtion[:SHAPe] {SINusoid|SQUare|PULSe|RAMP
|PRNoise|DC|SINC|GAUSsian|LORentz|ERISe|EDECay|HAVersine|USER[1]|
USER2|USER3|USER4|EMEMory|EFILe}
[SOURce[1|2]]:FUNCtion[:SHAPe]?
Arguments
SINusoid|SQUare|PULSe|RAMP|PRNoise|DC|SINC|GAUSsian|
LORentz|ERISe|EDECay|HAVersine
The following table shows the combination of modulation type and the shape of
output waveform.
If you select a waveform shape that is not allowed with a particular modulation,
sweep, or burst, the Run mode will automatically be changed to Continuous.
If you specify EFILe when there is no EFILe or the EFILe is not yet defined, this
command causes an error.
If you change the type of output waveform, it might change the output frequency
because changing waveform types impacts the setting range of output frequency.
USER[1]|USER2|USER3|USER4|EMEMory
A user defined waveform saved in the user waveform memory or the EMEMory
can be selected as an output waveform.
Sine, Square, Ramp, Arb, Sin(x)/x,
Gaussian, Lorentz, Exponential Rise,
Exponential Decay, Haversine
Pulse Noise, DC
AM √
FM √
PM √
FSK √
PWM √
Sweep √
Burst √√
