Tektronix AFG3000 Series Reference Manual

Reference
2-12 AFG3000 Series Arbitrary/Function Generators Reference Manual
Output Menu
Table 2-9 shows the Output Menu. To access the Output menu, push the
front-panel Top Menu button, and then push the bottom bezel button.
Table 2-9: Output Menu
First Level Second Level Description
Load Impedance 50 Ω Option buttons. Set the load impedance to 50 Ω.
Load
1
1. Range: 1 Ω to 10 kΩ.
When dBm is currently selected for output amplitude units, the amplitude units setting
is automatically changed to V
p-p
if you select high impedance.
Option buttons & Numeric input.
You can set the load impedance to any value
from 1 Ω to 10 kΩ.
High Z Option buttons. Select high impedance.
Invert
Off On
Selects Invert On to invert a waveform.
Limit High Limit Numeric input.
Specifies the higher and lower amplitude limit.
See Level Meter on page 1-12.
Low Limit
Noise Noise Add
Off On
Selects Noise Add On to add the internal noise
to a waveform.
Noise Level
2
2. Range: 0% to 50% of amplitude setting (V
p-p
) of signal waveform, resolution 1%
The maximum value of noise range is limited by waveform and amplitude range.
Sets the noise level.
External Add
3
Off On
3. AFG3100 and AFG3200 series only.
Selects External Add On to add an external
signal to the CH 1 output signal.
