Tektronix AFG3000 Series Reference Manual

Reference
2-14 AFG3000 Series Arbitrary/Function Generators Reference Manual
Edit Menu
The Edit menu is used to create or edit user-defined waveforms and to import or
export waveforms. To output a user-defined waveform, waveform data must be
created in the Edit Memory and then stored in the internal or a USB memory.
Although you can output the content of Edit Memory, the content of Edit Memory
will be deleted when the instrument is powered off.
There are three ways to create a waveform in the Edit Memory:
 Create a waveform file using the Edit Menu
 Copy a waveform file using remote commands
 Import a waveform file using the ArbExpress software
Table 2-11: Edit M enu
First Level Second Level Description
Number of Points Sets the number of points of waveform to be
created or the length of edit memory.
The default is 1000.
New Sine Writes a standard waveform to Edit Memory.
(The contents of Edit Memory will be
overwritten.) You can select a waveform from
five standard waveforms. The written waveform
has the number of points specified by the
Number of Points bezel menu.
Square
Pulse
Ramp
Noise
Operation Line Opens Line submenu. See Table 2-12.
Data Opens Data submenu. See Table 2-12.
Cut Opens Cut submenu. See Table 2-12.
(blank)
(blank)
Read from... Memory
Internal
USB
Selects a memory type (Internal or USB).
Read Load one of the user-defined waveforms, which
is stored in the internal or USB memory, to Edit
Memory. Once Read is executed, the edit
waveform is overwritten.
(blank)
Change Directory Opens a directory. This menu item is available
when USB is selected.
Cancel
-more- (1/3)
