AFG3000 Series Arbitrary/Function Generators Reference Manual 2-17
New. Pushing the New bezel button will display a standard waveform selection
submenu. You can select a standard waveform from five waveform types (Sine,
Square, Pulse, Ramp, and Noise). For example, selecting Sine will write a sine
waveform into Edit Memory. The waveform has the number of points specified by
the Number of Points bezel menu. If waveform data is already stored in the Edit
Memory, the existing waveform data will be lost, and the new waveform will over-
write the old data.
Operations Submenu (Line, Data, and Cut). For each of the Operations submenus,
you must push the Execute bezel button to implement the edit operation.
Table 2-12: Operations submenu
First level Second level Description
Line From X1 Use to edit a line linearly by interpolating from a
specified point in the waveform currently being
edited to another specified point.
Y1
To X 2
Y2
Execute
Data X Use to change the specified data point in the
waveform currently being edited.
Y
(blank)
(blank)
Execute
Cut From X1 Use to delete an area between specified points in
the waveform currently being edited.
(blank)
To X 2
(blank)
Execute
