2-6 AFG3000 Series Arbitrary/Function Generators Reference Manual
More... Menu
Table 2-5 shows the More... menu.
Table 2-5: More Menu
First Level Second Level Description
More Waveform Menu Sin(x)/x Option buttons
Noise
DC
Gaussian
-more- (1 of 2)
Lorentz Option buttons
Exponential Rise
Exponential Decay
Haversine
-more- (2 of 2)
Frequency/Period/
Phase Menu
Refer to Table 2-1
Amplitude/Level Menu Refer to Table 2-1
Run Mode Menu Continuous –––
Modulation Refer to Table 2-6
Sweep Refer to Table 2-7
Burst Refer to Table 2-8
Output Menu Refer to Table 2-9
NOTE. When the arbitrary/function generator outputs Sin(x)/x, Gaussian, Lorentz,
Exponential Rise, Exponential Decay, or Haversine waveforms, the peak-to-peak
voltage is defined as twice the 0 to peak value.
