Syntax and Commands

3-18 AFG3000 Series Arbitrary/Function Generators Reference Manual

DIAGnostic[:ALL]

The DIAGnostic[:ALL] command performs a self-test. The DIAGnostic[:ALL]?

command returns the results after executing the test.

Group

Calibration and Diagnostic

Related Commands

*TST?

Syntax

DIAGnostic[:ALL]

DIAGnostic[:ALL]?

Arguments

None

Returns

<NR1>

where

<NR1>=0 indicates that the self-test completed without errors.

<NR1>≠0 indicates that the arbitrary/function generator detected an error.

Examples

DIAGnostic:ALL

performs self-test.

DIAGnostic:ALL?

performs self-test and might return an error code.

NOTE. The self-test can take several minutes to complete. During this time, the

arbitrary/function generator does not execute any commands. Do not power off the

instrument during the self-test.
