Tektronix AFG3000 Series Reference Manual

Reference
2-20 AFG3000 Series Arbitrary/Function Generators Reference Manual
Cut (Cut by Data Points). The Cut deletes an area between specified points in the
waveform. When Cut is selected, two values can be input (From X1 and To X2).
See Figure 2-7.
Figure 2-7: Cut example
Read from... Push the front-panel Edit button and then push the Read from... >
Memory bezel menu to load a waveform file from the internal memory or a USB
memory into Edit Memory.
Before executing Cut
After executing Cut
NOTE. Data that has been deleted cannot be recovered.
