Tektronix AFG3000 Series Reference Manual

Reference
AFG3000 Series Arbitrary/Function Generators Reference Manual 2-21
Paste at Beginning. The Paste at Beginning inserts the contents of the user wave-
form memory (User1, User2, User3, or User4), USB memory, or the current
contents of Edit Memory at the beginning of the waveform that is currently being
edited. When this operation is executed, the Number of Points setting is automati-
cally modified. If this operation would cause the waveform to exceed 65,536
(AFG3021 and AFG3022) or 131,072 (AFG3101/AFG3102 and
AFG3251/AFG3252) points, the waveform insertion will not be executed.
Figure 2-8: Paste at Beginning
Stored waveform is pasted at the front of the
waveform being edited.
Waveform in Edit Memory
Waveform stored in internal or USB memory
Waveform after executing Paste at Beginning
1000
1000
1000
2000
