CSA7000B Series & TDS7000B Series Instruments User Manual

3- 139

Measuring Waveforms

The instrument comes equipped with cursors and automatic measurements to

assist you in analyzing your waveforms. This section describes these tools and

how you use them:

H Taking Automatic Measurements, on page 3--140, describes how you can

setup the instrument to automatically measure and display a variety of

waveform parameters. See Figure 3--34.

H Taking Cursor Measurements, on page 3--151, describes using cursors to

make measurements on waveforms. See Figure 3--34.

H Taking Histograms, on page 3--157, describes how to take histograms to

view the horizontal or vertical distribution of data on your waveforms.

H Optimizing Measurement Accuracy, on page 3--160, tells you how to run

compensation routines and how to deskew channels to optimize the accuracy

of your measurements.

NOTE. You can also make graticule measurements, counting graticule divisions

and multiplying them by the vertical or horizontal scales set for the waveform

that you are measuring.
