4.6 MDC Module 4 Replacement Procedures
Installing the MDC Module
Install the MDC module according to the following procedures and Figures 4-15, after
checking that the computer is turned off in boot mode.
CAUTION: Install the MDC module after turning off the computer. If this is violated,
the computer or MDC module can be damaged.
CAUTION: Do not touch the connectors on the MDC module or in the computer.
Contaminated connectors can cause MDC module failures.
1. Connect the MDC cable to connector J2 on the MDC module.
2. Connect the MDC module to CN17 on the system board.
3. Secure the MDC module with two M2x3 white bind screws.
Note: After the computer is turned on, check the hardware configuration in the
Hardware Setup or TSETUP program to make sure that the installed MDC
module has been recognized by the system. If it has not been recognized yet,
check the connections.
Qosmio F40/F45 Maintenance Manual 4-33
