Appendices Apx. C Pin Assignments
Qosmio F40/F45 Maintenance Manual C-5
C.7 CN7 Robson Module Connector (52-Pin)
Table C-7 Robson Module Connector Pin Assignments (52-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 - - 2 +V3S O
3 - - 4 DGND -
5 - - 6 +V1.5S O
7 - - 8 - -
9 DGND - 10 - -
11 CLK_R_PCIE_MINI1# O 12 - -
13 CLK_R_PCIE_MINI1 O 14 - -
15 DGND - 16 - -
17 - - 18 DGND -
19 - - 20 - -
21 DGND - 22 BUF_PLT_RST# O
23 PCIE_C_RXN3 I 24 - -
25 PCIE_C_RXP3 I 26 DGND -
27 DGND - 28 +V1.5S O
29 DGND - 30 - -
31 PCIE_C_TXN3 O 32 - -
33 PCIE_C_TXP3 O 34 DGND -
35 DGND - 36 - -
37 - - 38 - -
39 - - 40 DGND -
41 - - 42 - -
43 - - 44 - -
45 - - 46 - -
47 - - 48 +V1.5S O
49 - - 50 DGND -
51 - - 52 +V3S O
C.8 CN8 5 in 1 Memory Card Reader Connector (44-Pin)
Table C-8 5 in 1 Memory Card Reader Connector Pin Assignments (44-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 DGND - 2 MS_BS_SD_CMD_SM_WEZ I/O
3 MS_DATA1_SD_DAT1_SM_D1 I/O 4 MS_DATA0_SD_DAT0_SM_D0 I/O
To Next Page
