Appendices Apx. C Pin Assignments
Qosmio F40/F45 Maintenance Manual C-11
15 N$838144 -
C.21 CN802 HDMI Connector (19-Pin)
Table C-21 HDMI Connector Pin Assignments (19-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 N$1080927 - 2 N$988396 -
3 DGND - 4 HDMI_SDADDC O
5 HDMI_SCLDDC - 6 - -
7 - - 8 HDMI_L_TXC- O
9 DGND - 10 HDMI_L_TXC+ O
11 HDMI_L_TX0- O 12 DGND -
13 HDMI_L_TX0+ O 14 HDMI_L_TX1- O
15 DGND - 16 HDMI_L_TX1+ O
17 HDMI_L_TX2- O 18 DGND -
19 HDMI_L_TX2+ O 20
C.22 CN803 DC-IN Connector (6-Pin)
Table C-22 DC-IN Connector Pin Assignments (6-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 N$1158698 - 2 N$1158698 -
3 N$1158698 - 4 DGND -
5 DGND - 6 DGND -
C.23 CN806 USB Port0 / Port1 Connector (8-Pin)
Table C-23 USB Port0 / Port1 Connector Pin Assignments (8-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 USBVCC1 O 2 USB_L_P1- I/O
3 USB_L_P1+ I/O 4 DGND -
5 USBVCC1 O 6 USB_L_P0- I/O
7 USB_L_P0+ I/O 8 DGND -
To Next Page
