4.20 LCD Module 4 Replacement Procedures
Installing the 15.4-inch LCD Module
NOTE: LCD/FL cable must be carefully peeled away before disconnecting it from the
module.
Install the 15.4-inch LCD module according to the following procedures and Figures 4-35, 4-
36.
1. Turn the LCD upside down.
2. Connect the LCD/FL cable to the LCD module connector.
3. Turn the LCD right side up.
4. Place the LCD bracket in the correct position and secure it with three M2x3 black flat
head screws on each side.
5. Please the LCD module in the correct position and secure it with two M2.5x4 white
flat heat screws on each side.
Qosmio F40/F45 Maintenance Manual 4-65
