Appendices Apx. C Pin Assignments
C-8 Qosmio F40/F45 Maintenance Manual
C.13 CN15 Blue Tooth Board Connector (10-Pin)
Table C-13 Blue Tooth Board Connector Pin Assignments (10-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 DGND - 2 N$634761 O
3 BTRF-E3V O 4 CH_DATA I/O
5 N$1192610 - 6 BTMDL# I
7 CH_CLK I/O 8 USB_R_P6- I/O
9 USB_R_P6+ I/O 10 DGND -
C.14 CN16 Hot Key Board Connector (16-Pin)
Table C-14 Hot Key Board Connector Pin Assignments (16-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 +VLED O 2 +VLED O
3 +V3LA O 4 - -
5 LID_SW#_3 O 6 DGND -
7 DGND - 8 - -
9 - - 10 SCAN_OUT(13) O
11 SCAN_IN(7) O 12 SCAN_IN(6) O
13 SCAN_IN(5) O 14 SCAN_IN(3) O
15 SCAN_IN(2) O 16 SCAN_IN(1) O
C.15 CN17 MODEM Board Connector (12-Pin)
Table C-15 MODEM Board Connector Pin Assignments (12-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 DGND - 2 - -
3 MC97_3S_SDOUT I/O 4 - -
5 DGND - 6 MDC O
7 MC97_3S_SYNC I/O 8 DGND -
9 N$737061 I/O 10 DGND -
11 MC97_3S_RST# I/O 12 MC97_3S_BITCLK I/O
