Appendices Apx. C Pin Assignments
Qosmio F40/F45 Maintenance Manual C-21
9 DGND - 10 N$1057864 O
C.32 CN815 ODD Connector (50-Pin)
Table C-32 ODD Connector Pin Assignments (50-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 - - 2 - -
3 - - 4 - -
5 N$630731 O 6 SDD(8) I/O
7 SDD(7) I/O 8 SDD(9) I/O
9 SDD(6) I/O 10 SDD(10) I/O
11 SDD(5) I/O 12 SDD(11) I/O
13 SDD(4) I/O 14 SDD(12) I/O
15 SDD(3) I/O 16 SDD(13) I/O
17 SDD(2) I/O 18 SDD(14) I/O
19 SDD(1) I/O 20 SDD(15) I/O
21 SDD(0) I/O 22 PIDE_3S_DREQ I/O
23 DGND - 24 PIDE_3S_IOR# I/O
25 PIDE_3S_IOW# I/O 26 DGND -
27 PIDE_3S_IORDY I/O 28 PIDE_3S_DACK# I/O
29 PIDE_3S_IRQ I/O 30 - -
31 SDA(1) I/O 32 - -
33 SDA(0) I/O 34 SDA(2) I/O
35 PIDE_3S_CS#(0) I/O 36 PIDE_3S_CS#(1) I/O
37 - - 38 +V5S O
39 +V5S O 40 +V5S O
41 +V5S O 42 +V5S O
43 DGND - 44 DGND -
45 DGND - 46 DGND -
47 N$630734 O 48 DGND -
49 - - 50 DISK_IN I
C.33 CN817 IEEE 1394 Connector (4-Pin)
Table C-33 IEEE 1394 Connector Pin Assignments (4-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
To Next Page
