4 Replacement Procedures 4.10 Top Cover
4.10 Top Cover
Removing the Top Cover
Remove the top cover according to the following procedures and Figures 4-20 and 4-21.
1. Turn the computer upside down and remove the following 14 screws:
- fourteen M2.5x8 black bind screws
M2 5x8 black flat head screw.
M2 5x8 black flat head screw.
Figure 4-20 Removing the screws from the bottom of the computer
2. Turn the computer right side up.
3. Remove one M2.5x8 black flat head screw.
4. Disconnect the touch pad board flat cable from CN13.
5. Disconnect the Bluetooth cable from CN15.
6. Disconnect the FLICA flat cable from CN11.
7. Disconnect the LED board flat cable from CN1000.
8. . Disconnect the volume board flat cable from CN9.
4-40 Qosmio F40/F45 Maintenance Manual
