Appendices Apx. C Pin Assignments
Qosmio F40/F45 Maintenance Manual C-15
C.26 CN809 Express Card Connector (26-Pin)
Table C-26 Express Cad Connector Pin Assignments (26-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 DGND - 2 USB_P4- I/O
3 USB_P4+ I/O 4 CPUSB# I
5 - - 6 - -
7 ICH_3A_ALERT_CLK I/O 8 ICH_3A_ALERT_DAT I/O
9 +V1.5_EXP O 10 +V1.5_EXP O
11 PCIE_WAKE# I 12 +V3AUX_EXP O
13 PERST# O 14 +V3_EXP O
15 +V3_EXP O 16 EXPRESS_CLKREQ# O
17 CPPE# I 18 CLK_R_PCIE_CARD# O
19 CLK_R_PCIE_CARD O 20 DGND -
21 PCIE_C_RXN5 I 22 PCIE_C_RXP5 I
23 DGND - 24 PCIE_C_TXN5 O
25 PCIE_C_TXP5 O 26 DGND -
C.27 CN810 PCMCIA Connector (68-Pin)
Table C-27 PCMCIA Connector Pin Assignments (68-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 DGND - 2 ACARD_3S_AD0 I/O
3 ACARD_3S_AD1 I/O 4 ACARD_3S_AD3 I/O
5 ACARD_3S_AD5 I/O 6 ACARD_3S_AD7 I/O
7 ACARD_3S_CBE0# I/O 8 ACARD_3S_AD9 I/O
9 ACARD_3S_AD11 I/O 10 ACARD_3S_AD12 I/O
11 ACARD_3S_AD14 I/O 12 ACARD_3S_CBE1# I/O
13 ACARD_3S_PAR I/O 14 ACARD_3S_PERR# I/O
15 ACARD_3S_GNT# I/O 16 ACARD_3S_INT# I/O
17 ACARDVCC O 18 ACARDVPP O
19 N$965384 I/O 20 ACARD_3S_IRDY# I/O
21 ACARD_3S_CBE2# I/O 22 ACARD_3S_AD18 I/O
23 ACARD_3S_AD20 I/O 24 ACARD_3S_AD21 I/O
25 ACARD_3S_AD22 I/O 26 ACARD_3S_AD23 I/O
To Next Page
