Appendices Apx. C Pin Assignments
C-10 Qosmio F40/F45 Maintenance Manual
5 DGND - 6 HPS O
7 HP_OUTL O 8 HP_OUTR O
9 ANAGND - 10 MICS O
11 MIC_L O 12 MIC_R O
13 ANAGND - 14 LINE_S O
15 LINE_L O 16 LINE_R O
17 ANAGND - 18 ANAGND -
19 KILL_SWCH# O 20 +V3A O
C.18 CN20 USB Port2 / Port3 Connector (8-Pin)
Table C-18 USB Port2 / Port3 Connector Pin Assignments (8-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 DGND - 2 USB_L_P2- I/O
3 USB_L_P2+ I/O 4 USB_VCC2 O
5 USB_VCC2 O 6 USB_L_P3- I/O
7 USB_L_P3+ I/O 8 DGND -
C.19 CN800 SVIDEO Connector (4-Pin)
Table C-19 SVIDEO Connector Pin Assignments (4-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 DGND - 2 DGND -
3 SVID_L_LUMA O 4 SVID_L_CHROMA O
C.20 CN801 CRT Connector (15-Pin)
Table C-20 CRT Connector Pin Assignments (15-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 N$1091421 - 2 N$1091416 -
3 N$1091413 - 4 - -
5 DGND - 6 DGND -
7 DGND - 8 DGND -
9 N$838148 - 10 DGND -
11 - - 12 N$1163226 -
13 HSYNC O 14 VSYNC O
