Appendices Apx. C Pin Assignments
C-30 Qosmio F40/F45 Maintenance Manual
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 TD+ I/O 2 TD- I/O
3 RD+ I/O 4 LAN_45 I/O
5 LAN_45 I/O 6 RD- I/O
7 LAN_78 I/O 8 LAN_78 I/O
9 N$637812 - 10 LED_LANLINK# I/O
11 N$723050 - 12 N$1167994 -
C.49 JACK4000 External Microphone Connector (6-Pin)
Table C-49 External Microphone Connector Pin Assignments (6-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 N$1099626 - 2 N$1099621 -
3 N$1099619 - 4 MICS_AB I/O
5 AGROUND_AUDIO - 6 - -
C.50 JACK4001 Line In Connector (6-Pin)
Table C-50 Line In Connector Pin Assignments (6-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 AGROUND_AUDIO - 2 N$1099615 -
3 N$1099617 - 4 LINE_S#_AB I/O
5 AGROUND_AUDIO - 6 - -
C.51 JACK4002 Head Phone Connector (9-Pin)
Table C-51 Head Phone Connector Pin Assignments (9-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 AUDIO_GROUND - 2 N$1183097 -
3 N$1183098 - 4 HPS_AB I/O
5 N$1099639 - 6 - -
7 SPDIF_AB I/O 8 +V5S_SPDIF_AB O
9 AUDIO_GROUND -
