Appendices Apx. C Pin Assignments
C-16 Qosmio F40/F45 Maintenance Manual
27 ACARD_3S_AD24 I/O 28 ACARD_3S_AD25 I/O
29 ACARD_3S_AD26 I/O 30 ACARD_3S_AD27 I/O
31 ACARD_3S_AD29 I/O 32 ACARD_3S_D(2)_RFU I/O
33 ACARD_3S_CLKRUN# I/O 34 DGND -
35 DGND - 36 ACARD_3S_CD1# I/O
37 ACARD_3S_AD2 I/O 38 ACARD_3S_AD4 I/O
39 ACARD_3S_AD6 I/O 40 ACARD_3S_D(14)_RFU I/O
41 ACARD_3S_AD8 I/O 42 ACARD_3S_AD10 I/O
43 ACARD_3S_VS1# I/O 44 ACARD_3S_AD13 I/O
45 ACARD_3S_AD15 I/O 46 ACARD_3S_AD16 I/O
47 ACARD_3S_A18_RFU I/O 48 ACARD_3S_BLOCK# I/O
49 ACARD_3S_STOP# I/O 50 ACARD_3S_DEVSEL# I/O
51 ACARDVCC O 52 ACARDVPP O
53 ACARD_3S_TRDY# I/O 54 ACARD_3S_FRAME# I/O
55 ACARD_3S_AD17 I/O 56 ACARD_3S_AD19 I/O
57 ACARD_3S_VS2# I/O 58 ACARD_3S_RST# I/O
59 ACARD_3S_SERR# I/O 60 ACARD_3S_REQ# I/O
61 ACARD_3S_CBE3# I/O 62 ACARD_3S_AUDIO I/O
63 ACARD_3S_STSCHG I/O 64 ACARD_3S_AD28 I/O
65 ACARD_3S_AD30 I/O 66 ACARD_3S_AD31 I/O
67 ACARD_3S_CD2# I/O 68 DGND -
C.28 CN811 DDR2 DIMM1 Socket (200-Pin)
Table C-28 DDR2 DIMM1 Socket Pin Assignments (200-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 M_VREF I/O 2 DGND -
3 DGND - 4 M_DATA(4) I/O
5 M_DATA(0) I/O 6 M_DATA(5) I/O
7 M_DATA(1) I/O 8 DGND -
9 DGND - 10 M_DM(0) -
11 M_DQS#(0) O 12 DGND -
13 M_DQS(0) I/O 14 M_DATA(6) I/O
15 DGND - 16 M_DATA(7) I/O
17 M_DATA(2) I/O 18 DGND -
19 M_DATA(3) I/O 20 M_DATA(12) I/O
