4.7 Wireless LAN Card 4 Replacement Procedures
Installing the Wireless LAN Card
Install the wireless LAN card according to the following procedures and Figure 4-16.
1. Insert the wireless LAN card into the connector an angle of 45 degrees.
2. Press down on the wireless LAN card to secure it with two M2x3 white bind screws.
3. Connect the three antenna by pressing them firmly into place.
CAUTION: Do not touch the connectors on the wireless LAN card and in the computer
with your bare hands. Wireless LAN cards can fail if they are contaminated with sweat,
natural oils, etc. from your hands.
Qosmio F40/F45 Maintenance Manual 4-35
