4 Replacement Procedures 4.15
TV Tuner
Installing the TV Tuner
Install the TV Tuner according to the following procedures and Figure 4-30.
1. Insert the TV Tuner into the connector an angle of 45 degrees.
2. Press down on the TV Tuner to secure it with two M2x2 white bind screws.
CAUTION: Do not touch the connectors on the TV Tuner and in the computer with
your bare hands. TV Tuner can fail if they are contaminated with sweat, natural oils,
etc. from your hands.
4-54 Qosmio F40/F45 Maintenance Manual
