OPERATOR’S MANUAL
series Robot Controller
5.2.4 Deletion of Positional Data (ALT + BS)
(1) Function
Deletes a positional data.
(2) Procedures
Assume that you are going to delete the data of "POINT00005".
(a) Step 1: Selection of positional data.
Move the main cursor to "POINT00005", and the following display is called.
P O I N T X Y Z
↑
P O I N T 0 0 0 0 3 = 1 0 0 , 1 0 0 , 1 0 0 ,
P O I N T 0 0 0 0 4 = 2 0 0 , 2 0 0 , 2 0 0 ,
P O I N T 0 0 0 0 5 = 300 , 300 , 3 00 ,
P O I N T 0 0 0 0 6 = 4 0 0 , 4 0 0 , 4 0 0 ,
↓
P O I N T 0 0 0 0 7 = 5 0 0 , 5 0 0 , 5 0 0 ,
P O I N T 0 0 0 0 5 w / . w o r l d
S A V E P R G F U L L T R A N S P Y L D >
(b) Step 2: Deletion.
Press the ALT and BS keys at the same time, and the following display
appears with the specified data deleted.
P O I N T X Y Z
↑
P O I N T 0 0 0 0 3 = 1 0 0 , 1 0 0 , 1 0 0 ,
P O I N T 0 0 0 0 4 = 2 0 0 , 2 0 0 , 2 0 0 ,
P O I N T 0 0 0 0 6 = 400 , 400 , 4 00 ,
P O I N T 0 0 0 0 7 = 5 0 0 , 5 0 0 , 5 0 0 ,
↓
P O I N T 0 0 0 0 8 = 8 0 0 , 8 0 0 , 8 0 0 ,
P O I N T 0 0 0 0 6 w / . w o r l d
S A V E P R G F U L L T R A N S P Y L D >
(3) Caution
Different from the [CUT] function, you cannot undo a data deleted by this
operation.
STE 80720
– 5-15 –
