Appendix B
102
BACnet
®
MS/TP Object Set
Object Type
Device
Instance
*Units
Description
Writable
Notes and Range
Object
Value
Analog Input
1
in. W.C., Pa
Room1 Pressure
Analog Input
2
cfm, l/s, CMH
Supply Flow Rate
Analog Input
3
Air Changes Per
Hour
Analog Input
4
% RH
Relative Humidity
Analog Input
5
°F, °C
Room Temperature
Analog Input
6
cfm, l/s, CMH
Exhaust Flow Rate
Analog Input
7
in. W.C., Pa
Anteroom Pressure
1 room with Anteroom
configuration only
Analog Input
9
°F, °C
Supply Air
Temperature
Analog Input
10
Room 1 Label
Y
Writing to Object name will
change Rm1 Label item.
Room 1 Label object has not
applicable in. W.C. units.
Updating Room 1 Label
Object name will not
affect other Room 1
Object names.
Analog Input
11
Anteroom Label
Y
Writing to Object name will
change AnteRm Label
item.
Anteroom Label object has
not applicable in. W.C.
units.
Updating Anteroom Label
Object name will not
affect other Anteroom
Object names.
Analog Input
13
% Open
Supply Control
Output
Displays 0 if AO2 SIG TYPE
is not set to Supply
Control
0 to 100
Analog Input
14
% Open
Exhaust Control
Output
Displays 0 if AO1 SIG TYPE
is not set to Exhaust
Control
0 to 100
Analog Input
15
% Open
Reheat Control
Output
Displays 0 if AO2 SIG TYPE
is not set to Temp Control
0 to 100
Analog Value
1
in. W.C., Pa
Room 1 Neg Low
Alarm
Y
-0.19500 to
+0.19500 in. W.C.:
TSI Sensor
-1.0 in. W.C. to 1.0 in. W.C.:
Pressure Transducer
Analog Value
2
in. W.C., Pa
Room 1 Neg High
Alarm
Y
0.19500 to
+0.19500 in. W.C.:
TSI Sensor
-1.0 in. W.C. to 1.0 in. W.C.:
Pressure Transducer.
