Wiring Information
Back Panel Wiring
PIN #
Input /
Output /
Comm
Signal
Description
1, 2
Input
24 VAC/DC
Power in Digital Interface Module (DIM).
3, 4
Output
24 V
Power for TSI Pressure Sensors 24 VAC
5, 6
Input
0 to 10 VDC
Input 1
7, 8
Comm
RS-485
Communications between DIM and TSI
Pressure Sensors
9, 10
Output
Open / Closed
Relay 1 Output (Low Alarm)
11, 12
Output
Open / Closed
Relay 2 Output (High Alarm or Room Mode)
13, 14
Input
0 to 10 VDC
Input 2
15, 16
Input
0 to 10 VDC
Open / Closed
Input 3
17, 18
Input
Open / Closed
Input 4
19, 20
Input
0 to 10 VDC
Resistance
Input 5
21, 22
Input
Resistance
Open / Closed
Input 6
23, 24
Input
0 to 10 VDC
Resistance
Input 7
25, 26
Output
0 to 10 VDC
Exhaust Control Out
27, 28
Output
0 to 10 VDC
4-20 mA
Analog Out / Supply Control Out
29, 30
Output
0 to 10 VDC
4-20 mA
Analog Out / Temperature Control Out
31, 32, 33
Comm
RS-485
Nurse Station Display
31: B
32: A
33: Ref
34, 35, 36
Comm
Modbus /
BACnet MS/TP /
LON
BAS Communications
34: B
35: A
36: Ref (Modbus / BACnet MS/TP only)
