TSI Instruments PRESSURA RPC30 User Manual

42
Part Two
Interface Menu
MENU ITEM
SOFTWARE
NAME
ITEM DESCRIPTION
ITEM RANGE
DEFAULT
VALUE
Analog Output
Signal Type
AO1 Sig
Type
The AO1 Sig Type item selects the measurement that the
analog output signal will represent.
Exhaust Control,
None
Exhaust
Control
NOTE: Changing the AO1 Sig Type item when
Ctrl Device is set to EXHAUST or
EXHAUST/SUPPLY/TEMP may result in loss of
room or temperature control.
Analog Output
Signal Type
AO2 Sig
Type
The AO2 Sig Type item selects the measurement that the
analog output signal will represent.
Room 1 Pressure,
Exhaust Flow, Supply
Control, None
Room 1
Pressure
NOTE: Changing the AO2 Sig Type item when
Ctrl Device is set to EXHAUST/SUPPLY/TEMP
may result in loss of room or temperature control.
Analog Output
Signal
AO2 Out
Type
The AO2 Out Type item selects the analog output (not
control output signal).
0 to 10 VDC or
4-20 mA
0 to 10 VDC
NOTE: Changing the AO2 Out Type item when
Ctrl Device is set to EXHAUST/SUPPLY/TEMP
may result in loss of room or temperature control.
