TSI Instruments PRESSURA RPC30 User Manual

4
8
Part Two
Input1 Config Menu
Press Trans
MENU ITEM
SOFTWARE
NAME
ITEM DESCRIPTION
ITEM RANGE
DEFAULT
VALUE
Set Minimum
Sensor Pressure
Output
Sensor Min
The Sensor Min item is used to set the minimum reading
of a pressure transducer used to measure room pressure
differential. For example, if the pressure transducer has a
range of -0.25 in. W.C. to +0.25 in. W.C. (-62.5 to
+62.5 Pa), the Sensor Min should be set to -0.25 in. W.C.
(-62.5 Pa).
-1.00 to
+1.00 in. W.C.
0
Set Maximum
Sensor Pressure
Output
Sensor Max
The Sensor Max item is used to set the maximum reading
of a pressure transducer used to measure room pressure
differential. For example, if the pressure transducer has a
range of -0.25 in. W.C. to +0.25 in. W.C. (-62.5 to
+62.5 Pa), the Sensor Max should be set to +0.25 in. W.C.
(+62.5 Pa).
-1.00 to
+1.00 in. W.C.
0
Set Minimum
Sensor Voltage
Output
Signal Min
The Signal Min item is used to set the minimum output
signal when a pressure transducer is used to measure
room pressure differential.
0 to 5 V
0 V
Set Maximum
Sensor Voltage
Output
Signal Max
The Signal Max item is used to set the maximum output
signal when a pressure transducer is used to measure
room pressure differential.
1 to 10 V
10 V
Set Sensor Zero
Calibration
Sensor Zero
The Sensor Zero item is used to re-zero the pressure
transducer zero calibration point.
None
N/A
Reset Calibration
Reset Cal
The Reset Cal item is used to return to the factory default
calibration, undoing any field calibration adjustments. When
this menu item is entered, the controller will prompt the
user to verify that they want to do this by displaying the
message “Are You Sure.” Entering YES resets the
Sensor Zero factor for this sensor to defaults. Entering NO
will cancel the reset.
None
N/A
