TSI Instruments PRESSURA RPC30 User Manual

34
Part Two
Rm1 Setpnts Menu
MENU ITEM
SOFTWARE
NAME
ITEM DESCRIPTION
ITEM RANGE
DEFAULT
VALUE
Room1 Maximum
Exhaust Flow
Max Exh Flow
The Max Exh Flow item sets the maximum exhaust flow
rate for Room1.
0 to 10,000 CFM
NOTE
Max Exh Flow
cannot be set less
than the
Min Exh Flow
0 CFM
NOTE: Input7 must be configured for an exhaust flow
measurement for this item to be active. This item
can be adjusted even if not active.
Room1 Minimum
Exhaust Output
Min Exh Pos
The Min Exh Pos item sets the minimum output signal to
the exhaust control device.
0 to 100%
NOTE
Min Exh Pos
cannot be set
greater than the
Max Exh Pos
0%
Room1 Maximum
Exhaust Output
Max Exh Pos
The Max Exh Pos item sets the maximum output signal to
the exhaust control device.
0 to 100%
NOTE
Max Exh Pos
cannot be set less
than the
Min Exh Pos
100%
