Unify OpenScape CP400 User Manual

22 Getting to know the OpenScape Desk Phone CP400
Graphic display
Your OpenScape Desk Phone CP400 is equipped with a grey scale display  page 16.
Conversations
The conversations list appears in the main menu with the Conversations option and is a collection
of contact data and data from the call log. See from  page 29 for detailed information.
Main menu
Use the @ key to access the main menu at any time. The time, day of the week, and date as
well as the subscriber's own phone number are displayed. The main menu can do much more, as
can be seen from the screenshot. As the name suggests, it is the starting point for the entire menu
tree. However, as telephony features take priority on a telephone, it is the conversation list that is
used as the start display.
Conversations
3334
11:12
Paul Baum
10:57
3336
10:37
2
softkeys
Tuesday 23 May 2019
Conversations
forwarding on
Service/SettingsSer-
CFNR on

Unify OpenScape CP400 Specifications

General

Handset type	Wired handset
Product type	IP Phone
Product color	Black
Display diagonal	3.7 \
Backlight display	Yes
Display resolution	240 x 120 pixels
Volume control	Buttons
Number of programmable keys	16
Caller ID	-
Lines quantity	- lines
Phonebook capacity	1000 entries
Security algorithms	128-bit AES, 256-bit AES, HTTPS
Networking standards	IEEE 802.3az
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	IP v4/v6 (SIP) IPv4 (HFA), DHCP,
Number of handles included	- pc(s)
Operating system installed	Linux
Ringer type	MP3
Voice codecs	G.711, G.722, G.729, G.729A, G.729B
Safety	CISPR22 Class B, CISPR 24 EN55032 Class B, EN55024 FCC Part 15 (CFR 47) Class B
Certification	CE NRTL FCC Part 68 (CFR 47) / CS-03 Part V
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 70 °C
Headset connectivity	DHSG/EHS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	165 mm
Width	283 mm
Height	143 mm
Weight	1200 g
