7 Seat rail systems
⇒ “7.1 Assembly overview - seat rail systems”, page 96
⇒ “7.2 Removing and installing seat rails”, page 99
7.1 Assembly overview - seat rail systems
⇒ “7.1.1 Assembly overview - seat rail systems, middle seat rail,
for table module”, page 96
⇒ “7.1.2 Assembly overview - seat rail systems, middle seat rail,
for seats and benches”, page 97
⇒ “7.1.3 Assembly overview - seat rail systems, outer seat rail”,
page 98
⇒ “7.1.4 Assembly overview - seat rail systems, seat rails, per‐
manently installed seats and benches”, page 99
7.1.1 Assembly overview - seat rail systems, middle seat rail, for table module
1 - Front cover
2 - Cover, front centre
3 - Cover, front right
4 - Cover, rear centre
5 - Cover, rear right
6 - Seat rail base frame
❑ Removing and installing
⇒ page 99
7 - Rear cover
8 - Nuts
❑ Qty. 9, long wheelbase
❑ Qty. 7, short wheelbase
❑ 55 Nm
9 - Cover, rear left
10 - Cover, front left
Transporter 2016 ➤
General body repairs, interior - Edition 03.2020
96 Rep. gr.68 - Interior equipment
