3.1.2 Overview of fitting locations - airbag system, curtain airbag and crash sen‐
sors
1 - Curtain airbag in front seat
area on driver side
❑ Removing and installing
⇒ page 164
2 - Curtain airbag in front seat
area on front passenger side
❑ Removing and installing
⇒ page 164
3 - Curtain airbag in passenger
compartment on driver side
❑ Removing and installing
⇒ page 164
4 - Curtain airbag in passenger
compartment on front passen‐
ger side
❑ Removing and installing
⇒ page 164
5 - Rear side airbag crash sen‐
sor, front passenger side -
G257-
❑ Removing and installing
⇒ page 172
6 - Rear side airbag crash sen‐
sor, driver side - G256-
❑ Removing and installing
⇒ page 172
7 - Side airbag crash sensor,
front passenger side - G180-
❑ Removing and installing
⇒ page 172
8 - Side airbag crash sensor,
driver side - G179-
❑ Removing and installing
⇒ page 172
Transporter 2016 ➤
General body repairs, interior - Edition 03.2020
3. Airbag system 145
