– Release locking mechanism -2- on connector -1- in direction
of -arrow-.
– Disconnect connector -3-.
– Unscrew bolt -2-.
– Detach rear side airbag crash sensor on driver side - G256-
-1-.
Removing rear side airbag crash sensor on passenger side -
G257-
– Remove rear right sill panel moulding ⇒ page 224 .
– Release locking mechanism -2- on connector -1- in direction
of -arrow-.
– Disconnect connector -2-.
– Unscrew bolt -3-.
– Detach rear side airbag crash sensor on passenger side -
G257- -1-.
Installing
– Install in reverse order of removal, observing the following:
– Switch on ignition.
– Connect earth wire at battery negative terminal ⇒ Electrical
system; Rep. gr. 27 ; Battery; Disconnecting and connecting
battery .
Specified torques
♦ ⇒ “9.1 Overview of fitting locations - airbag crash sensors”,
page 172
Transporter 2016 ➤
General body repairs, interior - Edition 03.2020
9. Airbag crash sensors 175
