– Fit padding for window winder -1- onto window regulator shaft
before installing door trim.
– Clip window crank onto window lifter drive in locked position.
• After being installed, window winder must be in the position
shown with the window closed.
Note
♦
The illustration shows the left-hand window winder (right-hand
window winder is a mirror image).
♦
-Arrow- points forwards.
Installation position with window closed: angle -a- = 45° ± 12°
Continuation for all vehicles
Specified torques
♦ ⇒ “1.1 Assembly overview - front door trim”, page 176
Transporter 2016 ➤
General body repairs, interior - Edition 03.2020
1. Front door trims 179
