Volkswagen Transporter 2016 User Manual

Removing
– Operate backrest release mechanism -1-.
– Fold backrest -3- towards front in -direction of arrow-.
– Operate release lever -2- in -direction of arrow B-.
– Move seat to rearmost position.
– Use a screwdriver to release end cap of right, centre seat rail
-1- and pull out upwards.
– Use a screwdriver to release end cap of right seat rail -2- and
pull out upwards.
– Push cap -1- in -direction of arrow-.
– Remove cap -1- from seat rails -2-.
Transporter 2016 ➤
General body repairs, interior - Edition 03.2020
362 Rep. gr.72 - Seat frames

Volkswagen Transporter 2016 Specifications

General

Adjustable temperature control	Yes
Heater Control	Manual
Heated seats	Optional
Heated windshield	Optional
Rear heater	Optional
