Removing
– Switch off ignition.
– Disconnect vehicle battery ⇒ Electrical system; Rep. gr. 27 ;
Disconnecting and reconnecting battery .
– Remove rotating seat with seat frame on both sides
⇒ page 361 .
– Remove floor covering (if present) from vehicle.
– Remove trim on upper left and upper right sides of front bench
seat ⇒ page 412 .
– Remove trim on lower left and lower right sides of front bench
seat ⇒ page 414 .
– Remove lower trim of rear bench seat ⇒ page 416 .
– Separate front connectors -2- at coupling points -1-.
Transporter 2016 ➤
General body repairs, interior - Edition 03.2020
4. Rear seats, Business 419
