Note
Staples are destroyed during removal and must be renewed.
– Detach profile -5- in lower area on both left and right next to
backrest attachment from backrest frame.
– Roll cover off padding until the tensioning wires are accessi‐
ble.
– Unhook tensioning wire -4- on left and right from cover out of
wire frame in padding.
– Unhook tensioning wire -3- in upper area on left and right from
cover out of wire frame in padding.
– Unhook tensioning wires -1- and -2- in centre from cover out
of wire frame in padding.
Note
In case of vehicles with seat heating, remove cover separately. In addition, the wiring harness of the seat heating
must be detached when removing the seat heating.
Transporter 2016 ➤
General body repairs, interior - Edition 03.2020
1. Front seat covers and padding 449
