– Roll up cover -1- all round on outer sides.
– Unhook tensioning wires -4- from upholstery wire.
– Remove cover -1- and seat padding -2- from seat pan -3-.
Installing
– Installation is carried out in reverse order.
2.2.6 Separating cover and padding, Transporter, seat padding cover of double
bench seat, 2nd row
Removing
Note
Belt buckle trim need not be dismantled.
– Remove bench seat ⇒ page 361 .
– Remove centre belt buckle ⇒ page 135 .
– Remove seat padding ⇒ page 460 .
Transporter 2016 ➤
General body repairs, interior - Edition 03.2020
498 Rep. gr.74 - Seat - padding, covers
