OM 28Z3 US – Edition 2.0 * 28Z3b110.fm 1-23
Introduction
1.12 Fire extinguisher
The fire extinguisher is not supplied with the machine.
☞ Retrofitting a fire extinguisher according to NFPA must be performed by an authorized
Wacker Neuson service center.
☞ Location:
➥ In the cab, on the left in driving direction behind the seat (see Fig. 52).
☞ Installation:
• Mount the fire extinguisher on the cab profile according to the manufacturer’s instruc-
tions.
• The maximum hole diamenter is 6mm (0.24’’)
• The maximum number of holes is two.
Important!
Check the fire extinguisher at regular intervals, also make sure it is safely
mounted.
Fig. 52: Position of fire extinguisher
175 mm (7’’)
