3-26 OM 28Z3 US – Edition 2.0 * * 28Z3b330.fm
Operation
Tank for washer system
The tank's filler inlet is located in the engine compartment.
Important!
Use a blended mix of water and windshield washer fluid. A blended mix will mini-
mize freeze damage, prolong wiper life, and reduce streaking.
In winter: add antifreeze for washer systems to the water.
Refer to the antifreeze instructions for further information on concentrations.
The rubber diaphragm in the non-return valve in the housing sticks to itself if stored
in a dry condition over a longer period of time. In order to restore this valve's func-
tion, moisten this non-return valve, dip it briefly in water and then blow air through
it.
3.10 Seat
Seat adjustment
Caution!
Possible loss of machine control while adjusting the seat.
• Do not adjust the seat position during machine operation or travel.
– see Before starting the engine on page 3-12
• Adjust the seat before moving the machine.
NOTICE
Possible window damage from adjusting the backrest.
• Make sure the backrest does not touch the rear window or the remov-
able part of the front window as you adjust backrest inclination.
• Select a seat position which will not damage the window panels when
working with the machine.
Fig. 23: Tank for washer system
Fig. 24: Seat adjustment
