OM 28Z3 US – Edition 2.0 * 28Z3b330.fm 3-31
Operation
3.14 Door
Important!
Possibility of equipment damage or injury to others. An open door on a moving
machine may slam against the machine, damaging the door frame or window
glass. The door may also strike nearby objects or people.
• Always make sure that doors and windows are closed before moving the
machine.
Opening the door from the outside:
☞ Press door lock A.
Locking the door:
☞ Turn the key in door lock A counter-clockwise (L).
☞ The door is locked.
Unlocking the door:
☞ Turn the key in door lock A clockwise (R).
☞ The door is unlocked.
Opening the door from the inside:
☞ Push the latch lever down to unlatch the door.
Securing an open door:
☞ Press the door against bracket C of latch D with an audible click.
Fig. 32: Outside door opener and lock
A
R
L
Fig. 33: Inside door opener (left/right)
B
Fig. 34: Door arrester
C
D
