Technical data
BA RD24_RD28 en us 06
135
5.01.02 RD 24-100 O
Designation Value Unit
Dimensions and weights
Unladen weight without ROPS roll-over bar 2284 kg
Operating weight with ROPS roll-over bar 2525 kg
Axle load front / rear 1205 / 1320 kg
Working width / max. working width 1000 / 1050 mm
Turning radius inside / outside 2470 / 3470 mm
Diesel engine
Manufacturer Kubota
Type D1703
Number of cylinders 3
Power (ISO 14396) / rated speed 22.9 / 2700 kW / rpm
Emission level EU / USA V/Tier 4
Carbon dioxide emissions (CO
2
)
(1)
938.3 g/kWh
Transmission
Working gear speed 0 - 12 / (0 - 7.5) km/h / (mph)
Climbing ability, vibration on / off 30 / 40 %
Max. longitudinal gradient allowed 20 °
Max. transverse gradient allowed 20 °
Vibration
Vibration front
Frequency / speed, engine speed max. 67 / 4020 Hz / rpm
Frequency / speed, engine speed 2/3 max. 52 / 3120 Hz / rpm
Maximum amplitude 0.45 mm
Oscillation
Oscillation rear
Frequency / speed, engine speed max. 39 / 2340 Hz / rpm
Frequency / speed, engine speed 2/3 max. 30 / 3000
Tangential amplitude 1.34 mm
Steering
Steering angle to both sides 32 °
Pendulum compensation upwards and downwards 8 °
Track offset
Track offset to the right 50 mm
