Tables
Fuses
BA RD24_RD28 en us 06
147
5.03 Fuses
WARNING
Fire hazard if fuses are not inserted correctly!
■
Insert only specified fuses (no fuses with a higher amperage!).
■
Do not install a bypass to the fuses.
002-46
Fuses
Position Fuse assignment Fuse
F01 Main fuse on the battery 80 A
F1 All-wheel lock 5 A
F2 Time relay cold start assistance 1 A
F3 Drum edge lighting 15 A
F4 Driving light, left 10 A
F5 Driving light, right 10 A
F6 Reversing lights 15 A
F7 Working spotlight 15 A
F8 Cold start assistance pilot light 5 A
F9 not used 5 A
F10 Pedal switch sprinkling 15 A
F11 Pedal switch additive sprinkling, seat heating 15 A
F12 not used
F13 Socket 15 A
F14 Signal horn 15 A
F15 Additive sprinkling pump 15 A
F16 Water sprinkling pump 15 A
F17 Rotating light 15 A
FT Header for fuse test
NOTE
The green light-emitted diode (LED) lights up when the fuse is functional.
